Operating weight (kg) (actual weight + 75 kg operator):
1028
|
|
Bucket capacity (m³):
0.014
|
|
Travel speed low/high (km/h):
0-1.5
|
|
Gradeability (%):
0.3
|
|
Ground pressure (kPa):
25.53
|
|
Max. digging force (kN):
9.2
|
|
Max. digging radius (mm):
2852
|
|
Max. digging depth (mm):
1562
|
|
Max. digging height (mm):
2479
|
|
Max. dumping height (mm):
1826
|
|
Max. boom swing angle (°):
not available
|
|
Undercarriage track adjustment (mm):
not available
|
|
Engine make:
Ligong (Euro 5)
|
|
Engine model:
192F
|
|
Max. power (hp):
10.4
|
|
Max. power (kW):
7.5
|
|
Max. engine speed (rpm):
3000
|
|
Displacement (L):
0.499
|
|
Number of cylinders:
1
|
|
Cooling:
Air-cooled
|
|
Fuel type:
Diesel
|
|
Fuel grade:
Diesel no. 0 / no. -10
|
|
Theoretical fuel consumption (L/h):
0.8-1.2
|
|
Cab (equipment):
Option
|
|
Armrest:
Option
|
|
Quick coupler:
Option
|
|
Hydraulic quick coupler:
not available
|
|
Rake:
Option
|
|
Timber grab:
Option
|
|
Ripper tooth:
Option
|
|
Hydraulic breaker:
Option
|
|
Counterweight:
Standard
|
|
Track tensioning:
Mechanical tensioning
|
|
Air conditioning:
Heating only
|
|
Transport length (mm):
2171
|
|
Transport width (mm):
917
|
|
Transport height (mm):
2178
|
|
Ground clearance counterweight (mm):
370
|
|
Bucket width (mm):
300
|
|
Boom length (mm):
1477
|
|
Dipper arm length (mm):
800
|
|
Dozer blade width (mm):
885
|
|
Fuel tank (L):
8.5
|
|
Hydraulic oil tank (L):
12.5
|
|
Rubber track (width*pitch*links):
180*72*37
|
|
Steel track (width*pitch*links):
180*72*37
|
|
Rubber pads (pcs):
74
|
|
Max. main pump flow (L/min):
18L/min
|
|
Control valve:
2+2+5 sections
|
|
Rated relief pressure (MPa):
16MPa
|
|
Max. relief pressure (MPa):
18MPa
|
