Operating weight (kg) (actual weight + 75 kg operator):
2439
|
|
Bucket capacity (m³):
0.054
|
|
Travel speed low/high (km/h):
0-1.5/0-2.8
|
|
Gradeability (%):
0.3
|
|
Ground pressure (kPa):
33.4
|
|
Max. digging force (kN):
18.4
|
|
Max. digging radius (mm):
4143
|
|
Max. digging depth (mm):
2293
|
|
Max. digging height (mm):
3761
|
|
Max. dumping height (mm):
2496
|
|
Max. boom swing angle (°):
125
|
|
Undercarriage track adjustment (mm):
1300-1500
|
|
Engine make:
Kubota
|
|
Engine model:
D1105
|
|
Max. power (hp):
22.93
|
|
Max. power (kW):
17.1
|
|
Max. engine speed (rpm):
3000
|
|
Displacement (L):
1.123
|
|
Number of cylinders:
3
|
|
Cooling:
Water-cooled
|
|
Fuel type:
Diesel
|
|
Fuel grade:
Diesel no. 0 / no. -10
|
|
Theoretical fuel consumption (L/h):
1.3-1.5
|
|
Cab (equipment):
Standard
|
|
Armrest:
not available
|
|
Quick coupler:
not available
|
|
Hydraulic quick coupler:
Option
|
|
Rake:
Option
|
|
Timber grab:
Option
|
|
Ripper tooth:
Option
|
|
Hydraulic breaker:
Option
|
|
Counterweight:
Standard
|
|
Track tensioning:
Grease tensioner
|
|
Air conditioning:
Standard
|
|
Transport length (mm):
2824
|
|
Transport width (mm):
1540
|
|
Transport height (mm):
2361
|
|
Ground clearance counterweight (mm):
510
|
|
Bucket width (mm):
450
|
|
Boom length (mm):
1830
|
|
Dipper arm length (mm):
1250
|
|
Dozer blade width (mm):
1540
|
|
Fuel tank (L):
28
|
|
Hydraulic oil tank (L):
37
|
|
Rubber track (width*pitch*links):
250*47RS*84
|
|
Steel track (width*pitch*links):
250*90*43
|
|
Rubber pads (pcs):
86
|
|
Max. main pump flow (L/min):
67.2
|
|
Control valve:
9-section pilot-operated control valve
|
|
Rated relief pressure (MPa):
20MPa
|
|
Max. relief pressure (MPa):
27MPa
|
