Operating weight (kg):
784
|
|
Bucket capacity (m³):
0.15
|
|
Rated payload (kg) (safe load):
175
|
|
Max. payload (kg):
400
|
|
Travel speed low/high (km/h):
0-2.5
|
|
Gradeability (%):
0.25
|
|
Ground pressure (kPa):
44.05
|
|
Max. dumping height (mm):
1553
|
|
Max. lifting height (mm):
2080
|
|
Max. dumping reach (mm):
550
|
|
Min. ground clearance (mm):
108
|
|
Engine make:
Kubota
|
|
Engine model:
Z482
|
|
Max. power (hp):
11.23
|
|
Max. power (kW):
8.2
|
|
Max. engine speed (rpm):
3000
|
|
Displacement (L):
0.479
|
|
Number of cylinders:
2
|
|
Cooling:
Water-cooled
|
|
Fuel type:
Diesel
|
|
Fuel grade:
Diesel no. 0 / no. -10
|
|
Theoretical fuel consumption (L/h):
0.8-1.2
|
|
Cab (equipment):
not available
|
|
Cab roof:
not available
|
|
Armrest:
Standard
|
|
Quick coupler:
Standard
|
|
Hydraulic quick coupler:
not available
|
|
4-in-1 bucket:
Option
|
|
Pallet forks:
Option
|
|
Sweeper:
Option
|
|
Hydraulic breaker:
Option
|
|
Counterweight:
not available
|
|
Track tensioning:
Mechanical tensioner
|
|
Air conditioning:
not available
|
|
Transport length with bucket (mm):
1970
|
|
Transport length without bucket (mm):
1520
|
|
Transport width (mm):
1150
|
|
Transport height (mm):
1300
|
|
Bucket width (mm):
1150
|
|
Fuel tank (L):
11
|
|
Hydraulic oil tank (L):
25
|
|
Model:
18*8.50-8
|
|
Max. main pump flow (L/min):
18+12+12
|
|
Working relief pressure (MPa):
14.5MPa
|
|
Travel drive relief pressure (MPa):
14.5MPa
|
